Extreme space weather threatens vital satellites orbiting the Earth, including the Global Navigation Satellite Systems (GNSS) which pass through the heart of the outer radiation belt. New research led by the British Antarctic Survey (BAS), has determined, for the first time, a series of benchmarks for the likely severity of extreme space weather events in GPS orbit.

High-energy ‘relativistic’ electrons – so-called “killer” electrons – are a major source of radiation damage to satellites and so understanding their patterns of activity is crucial. Bursts of charged particles and magnetic fields from the Sun can tear open the Earth’s magnetic field, giving rise to geomagnetic storms. During these events the number of killer electrons in the outer radiation belt can increase by orders of magnitude and become a significant space weather hazard.

Dr Nigel Meredith of BAS led an international team who analysed 20 years of data from a US GPS satellite to determine the 1 in 10, 1 in 50 and 1 in 100-year event levels. A 1 in 100-year event is an event of a size that will be equalled or exceeded on average once every 100 years.

The Aurora over Halley Research Station – a sign of elevated space weather. (BAS/Antony Dubber)

Satellite operators, manufacturers, insurers, and governments need to prepare and mitigate against the risks posed by these electrons.  Society is increasingly reliant on satellites for a variety of applications including communication, navigation, Earth observation and defence. As of April 2022, there were 5,465 operational satellites in Earth orbit, and most are exposed to energetic electrons for at least some of their orbit. In 2021, the overall global space economy generated revenues of $386 billion, an increase of four percent compared to the previous year.

Dr Nigel Meredith, space weather scientist and lead author of the study says:

“The 1 in 100 year event levels reported in this study are important for industry and government. They serve as benchmarks against which to compare other extreme space weather events and to assess the potential impact of an extreme event.”

These findings are vitally important to the satellite industry as engineers and operators require realistic estimates of the largest electron fluxes encountered in GPS orbit to prepare for the impacts of these extreme events and to improve the resilience of future satellites. The findings are essential for satellite insurers to help them ensure satellite operators are doing all they can to reduce risk and to evaluate realistic disaster scenarios.

The difference between the 1 in 10 year and 1 in 100-year event varies depending on the energy of the electrons and the distance from Earth. These differences are largest at the highest energies furthest from the planet, varying between a factor of 3 and 10 for some of the highest electron energies over 35,000 km from the Earth’s surface. Such substantial increases could pose a significant additional risk to satellites operating in this region.

Like weather on our planet, space weather can vary greatly over minutes, days, seasons and the 11-year solar cycle. The researchers found that the majority of these killer electron events occurred during the solar cycle’s declining phases — seen twice during the 20- year period they studied — but the largest event was elsewhere, showing that extreme events can happen at any time.

Professor Richard Horne, FRS, from BAS and a co-author on the study, says:

“The space sector is part of our Critical National Infrastructure.  This research will help us assess the resilience of satellites to a severe space weather event.”

Severe space weather was added to the UK National Risk Register of Civil Emergencies in 2011. The impacts of space weather on satellites can range from momentary interruptions of service to total loss of capabilities. In 2003 a major storm caused 47 satellites to experience anomalies, over 10 to be out of action for more than a day and one was a complete loss.

Extreme Relativistic Electron Fluxes in GPS Orbit: Analysis of NS41 BDD-IIR Data
by Nigel P. MeredithThomas E. CaytonMichael D. CaytonRichard B. Horne is published in the journal Space Weather



Key context

  • Global Navigation Satellite Systems such as the US Global Positioning System (GPS), the European Galileo navigation system, the Russian GLONASS system, and the Chinese  Beidou system operate in MEO at altitudes between 19,000 and 24,000 km. They all thus pass through the heart of the outer radiation belt where they may be exposed to large fluxes of relativistic electrons.
  • GNSS-enabled devices are used ubiquitously all over the world for navigation, positioning, tracking, mapping and timing. For example, in 2021 there were 6.5 billion GNSS devices in use and this is expected to rise to 10.3 billion by 2031 (EUSPA EO and GNSS Market Report, 2022). In 2021 the global downstream market revenue from both GNSS-enabled devices and services was 199 billion Euros and  this is expected to grow to 492 billion Euros by 2031, largely fuelled by expected revenues from added value services.
  • It is therefore important to have a comprehensive understanding of the environment encountered by  satellites in GNSS-type orbits and, in particular, knowledge of the likely extremes of this  environment to be able to better protect space assets operating in this region.
